HVSS Pneumatic Flow Control Valve Hand Thread To Thread Connector Push In 2Way / 3 Way Fittings Sanmin
Specification
1) Brass with good nice nickel plated.
2) BSPT thread (British Standard Taper Pipe Thread).
3) Each and every pcs was tested at 10kgs/cm2.
4) Thread with PTFE coating which can seal directly without any other seal material.
Application
Used for turning air pressure on and off for pneumatic devices
Features
The three-way valve , when the air is stopped , discharges residual pressure to outlet , which assures safety in repairing or adjusting connected devices .
The two-way valve dose not discharge residual pressure
There are four types of hand valves for choosing
Three – way valves
The three – way valve , when the air is stopped , discharges residual pressure to outlet , which assures safety in repairing or adjusting connected devices .
The two – way valve dose not discharge residual pressure , and suitable for the tank or other device that does not require a discharging residual pressure .
| Fluid | Air ( no other gases or liquids ) |
| Operating Pressure | 0~150 psi 0~9.9kgf/cm⊃2; (0-990kpa) |
| Negative Pressure | -29.5 in Hg -750mmHg |
| Operating Temperature | 32 ~ 140 ℉ 0~60℃ |
| Applicable Tube | Polyurethane and Nylon |
FAQ
Q: Do your company have specialized technical personnel ?
A: Design as your requirements,and have QC for make 100% inspection
Q: Can the product be made with our logo and brand ?
A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization for work.
Q: What ' s your delivery date ?
A: It depends on the number of orders . Delivery date is 7 - 30 days .if small order,pls buy from our aliexpress shop, If you need emergency products , we can speed up the production of the first arrangement .
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Why choose us
1: Reliable quality assured and active after-sell service
2: Various style for each products and completely series pneumatic products .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
